2019-10-02 by Alon Bar David

Patterns for deriving state

Common and advanced use-cases for deriving state in applications

state derive transition I was going to write an article about why you should derive state and not sync it manually, but Kent C. Dodds has written an excellent article on the subject.

So instead I'm going to go over a few common situations I've seen throughout the years and how to handle them without syncing state manually.

Filtering and sorting lists

Filtering and sorting lists or tables is a very common situation in web development.
The straightforward way is to keep a sorted list and resort it as things get updated.

class SortedList extends React.Component {

    onFilterChange = (event)=>{
        const filter = event.target.value;
        const {sortKey} = this.state;
        const filteredList = this.props.list.filter(item=>item.text.indexOf(filter)>=0)
        this.setState({
            filter,
            sortedList:sortByColumn(filteredList,sortKey)
        })
    }
    sortByKey = (column) =>{
        const sortedList = sortByColumn(this.state.list,column);
        this.setState({
            sortedList,
            sortKey:column
        })
    }
    render(){
        const {sortedList,filter} = this.state;
        return <div>
            {sortedList.map(item=>
                <ItemView item={item} key={item.id} />
            )}
            <button onClick={()=>this.sortByKey("columnA")}>Sort by A</button>
            <button onClick={()=>this.sortByKey("columnB")}>Sort by B</button>
            <input type="text" value={filter}
                onChange={this.onFilterChange}>Sort by A</button>
        </div>
    }
}

function sortByColumn(list,column){
     return list.sort((a,b)=>a[column]>b[column]?1:a[column] < b[column]?-1:0)
 }

Handling state like this manually is prone to errors in the future when more functionality is added. We call sortByColumn from two different places, and we'll need to do it for every different transformation we do on the original list.

If we derive sorting, we'll instead do this:

class SortedList extends React.Component {

    onFilterChange = (event)=>{
        const filter = event.target.value;
        this.setState({
            filter,
        })
    }
    sortByKey = (column) =>{
        this.setState({
            sortKey:column
        })
    }
    sortList(){
        const {list} = this.props;
        const {filter,sortKey} = this.state;
        const filteredList = list.filter(item=>item.text.indexOf(filter)>=0)
        return list.sort((a,b)=>a[column]>b[column]?1:a[column] < b[column]?-1:0)
    }
    render(){
        const {filter} = this.props;
        const sortedList = this.sortList();
        return <div>
            {sortedList.map(item=>
                <ItemView item={item} key={item.id} />
            )}
            <button onClick={()=>this.sortByKey("columnA")}>Sort by A</button>
            <button onClick={()=>this.sortByKey("columnB")}>Sort by B</button>
            <input type="text" value={filter}
                onChange={this.onFilterChange}>Sort by A</button>
        </div>
    }
}

Showing elapsed time

The usual way of showing a ticking clock from (or to) a certain time is to use setInterval to update how much time is left.

    function ticker(){
        const [time,setTime] = useState(0);
        useEffect(()=>{
            const intervalId = setInterval(()=>setTime(time+1),1000)
            return ()=>clearInterval(intervalId)
        })
        return <div>
            seconds elapsed {time}
        </div>
    }

While this code works we are managing state that can be derived instead.

This approach breaks when we need to update the start time, show different granular times and when you consider that setInterval doesn't really guarantee it'll run in exactly the time interval (it only guarantees that it'll run after the specified time but if something blocks it could run at any point in the future).

An often better approach is to save the original start date and derive the elapsed time using the current time:

    function ticker(){
        const [renderTimes,rerender] = useState(0);
        const now = new Date().getTime();
        const [start] = useState(now);
        //we use this to force the function to rerender every second
        useEffect(()=>{
            const intervalId = setInterval(()=>rerender(renderTimes + 1),1000)
            return ()=>clearInterval(intervalId)
        })
        return <div>
            seconds elapsed {Math.floor((now - start)/1000}
        </div>
    }

I know force rendering is usually an anti-pattern, but there really isn't another way in this case for us to tell react when it should rerender.

If you are using mobx there's already a good utility function that does exactly this - the 'now()' function from mobx-utils

Showing selected items in a checklist

A common pattern I've seen when creating a checklist is to put what items were selected inside the state that contains the options.
For example let's try to build a list of things you can put in a burger:

import React,{useState} from 'react';

// ToppingSelection receives props with the following structure (Typescript notation):
// {options:{text:string,value:string},selected:string[],onChange:(value)=>void}
class ToppingSelection extends React.Component {

    constructor(props){
        super(props);
        this.state = {
            optionsWithSelect:_.cloneDeep(props.options) // _ is for lodash, which I use for clarity
        }
    }

    handleInputChange = (event)=>{
        const value = event.target.name;
        const {optionWithSelect} = this.state;
        const index = optionWithSelect.indexOf(o=>o.value ===value);
        if (optionWithSelect[index].selected){
            this.uncheckOption(index);
        } else {
            this.checkOption(index);
        }
    }
    uncheckOption(index){
        const optionWithSelect = _.cloneDeep(this.state.optionWithSelect);
        optionWithSelect[index].selected = false;
        this.setState({
            optionWithSelect
        })
        this.props.onChange(optionWithSelect.filter(o=>o.selected).map(o=>({text:o.text,value:o.value}))
    }
    checkOption(index){
        const optionWithSelect = _.cloneDeep(this.state.optionWithSelect);
        optionWithSelect[index].selected = true;
        this.setState({
            optionWithSelect
        })
        this.props.onChange(optionWithSelect.filter(o=>o.selected).map(o=>({text:o.text,value:o.value}))
    }
    render(){
        const {optionsWithSelect} = this.state;
        return <div>
            {options.map(option=>
                <label key={option.value}>
                    {option.text}
                    <input type={checkbox} checked={optionsWithSelect.checked}
                    onChange=(this.handleInputChange} name={option.value} />
                </label>
            )}
        </div>
    }
}

This isn't very good react code and perhaps a bit contrived as it's not even a fully controlled component but it's a very common pattern in use and it's very enticing when your options object becomes more complex.

It also disregards all selected choices if the list of options changes.
Because it manages the state internally the function has to take care to sync it's internal representation with external changes.

Instead:

// ToppingSelection receives props with the following structure (Typescript notation):
// {options:{text:string,value:string},selected:string[],onChange:(value)=>void}
class ToppingSelection extends React.Component {

  handleInputChange = (event)=>{
      const value = event.target.name;
      if ( selected.includes(value)){
          onChange(selected.filter(option=>option !== value));
      } else {
          onChange(selected.concat(value));
      }
  }
  render(){
      const {options,selected} = this.props;
        return <div>
            {options.map(option=>
                <label key={option.value}>
                    {option.text}
                    <input type={checkbox} checked={selected.includes(option.value)}
                    onChange=(this.handleInputChange} name={option} />
                </label>
            )}
        </div>
  }
}

Yes we are actually iterating over all the selected array for each option so this is more or less an O(n^2) operation where n is the number of options. (O(n^2) is a Big O notation This won't be close to a performance issue if the number of options is small and if the number of options is big enough to become an issue than you probably need to consider a different UI paradigm then a checklist.

There are also ways to make this function perform at O(n), which is equivalent to the previous example in performance but in exchange for a much more verbose and complicated code.

Deriving state isn't limited only to the view layer

Most examples for deriving state focus on how to limit syncing state inside a component, but in larger applications we often keep much of our state outside the view layer - inside the logic layer (controller in MVC, or stores for most state management frameworks these days).

It's also important to limit what state you derive inside you logic layer - even with frameworks that discourage syncing state such as redux.

Take for example the same list sorting example from before, but this time written in redux:

    function sortingReducer(state,action){
      switch (action.type){
        case actionTypes.SORT_BY:
          const key = action.payload;
          return {
            list:state.list.sort((a,b)=>a[key]>b[key]?1:a[key]<b[key]?-1:0),
            sortKey:key
          }
          default:
            return state;
      }
    }

By manually sorting inside our store we'll have to take care to sort the list again if a different action causes the list to change.

Instead to derive the state we would write it like this:

    function sortingReducer(state,action){
      const key = action.type === actionTypes.SORT_BY?action.payload:state.sortKey;
      return {
        list:state.list,
        sorted:state.list.sort((a,b)=>a[key]>b[key]?1:a[key]<b[key]?-1:0),
        sortKey:key
      }
    }

This is less performance, but as always if performance becomes an issue there are ways around it by using memoization.

Setters for derived state

When your stores expose a derived property, we often want to be able to change that derived property. We can do so by creating actions that take the new derived state and infer the proper original state.

For example let's take a store that keeps a time interval for displaying a graph at a certain range. We would like to keep the store simple and use only time in days, but for the user we would like to show dates that are more human readable (I.E. 1 week, 4 months, etc...)

An example for such a store that uses derived state would look something like this:

    function timeRangeReducer(state,action){
      let days = state.days;
      if (action.type === actionTypes.SET_DAYS){
        days === action.payload;
      }
      return {
        days,
        formatted: days > 14? `${Math.floor(days / 7)} weeks`:days>1?`${days} days`:'1 day'
      }
    }

Instead of exposing just a function that changes the day and letting the user (usually the view layer) be in charge of converting from our derived state to the internal representation, we could expose a setter for the formatted field:


    function setSetDays(days){
      return (dispatch,getState)=>{
        dispatch({
          type:actionTypes.SET_DAYS,
          payload:days
        })
      }
    }
    function setFormatted(formatted){
      return (dispatch,getState)=>{
        const [count,unit] = formatted.split(" ");
        const days = unit === "weeks"? count * 7: count;
        dispatch({
          type:actionTypes.SET_DAYS,
          payload:days
        })
      }
    }

This is a bit of a contrived example since you should probably format this inside the component and not in the store, but it'll do to explain the point.

In mobx we can do this by creating a setter for a computed property:

    class TimeRangeStore {
      @observable
      days;

      constructor(days){
        this.days = days;
      }

      @computed
      get formatted(){
        const {days} = this;
        return days > 14? `${Math.floor(days / 7)} weeks`:days>1?`${days} days`:'1 day'
      }

      @action
      set formatted(value){
          const [count,unit] = value.split(" ");
          const days = unit === "weeks"? count * 7: count;
          this.days = days;
      }
}

Why I used class syntax for most examples and not hook syntax

I originally tried to write all the examples using the new hook syntax, however it became obvious very quickly that writing examples of syncing states manually with hooks results in very convoluted code that doesn't seem like anyone would actually use.
Since I've seen instances of these cases being used often with class syntax and haven't had the pleasure of seeing anyone using it with hook syntax, I've opted to write the bad code examples using what I've actually seen in practice.

Since I wrote the bad examples in class syntax I've opted to show the good examples in class syntax too, both to not imply a preference of one syntax over the other in this article and so that the changes would be more directly apparent.

That said I think the fact that hooks are naturally a single function and imply a certain linear flow makes writing unnecessary state management harder - and writing derived state more natural.

Hooks make writing react code using best practices more natural

Here's the hook syntax code for both examples which were written in class syntax:

Filtering and sorting lists

function sortedList(props){
    const {list) = props;
    const [filter, setFilter] =  useState("");
    const [sortKey, setSortKey] = useState(null);

    const filteredList = list.filter(item=>item.text.indexOf(filter)>=0)
    const sortedList = list.sort((a,b)=>a[column]>b[column]?1:a[column] < b[column]?-1:0);
    return <div>
        {sortedList.map(item=>
            <ItemView item={item} key={item.id} />
        )}
        <button onClick={()=>setSortKey("columnA")}>Sort by A</button>
        <button onClick={()=>setSortKey("columnB")}>Sort by B</button>
        <input type="text" value={filter}
            onChange={setFilter}>Sort by A</button>
    </div>
}

Showing selected items in a checklist

function ToppingSelection(props){
    const {options,selected,onChange} = props;

    function handleInputChange(event){
        const value = event.target.name;
        if ( selected.includes(value)){
            onChange(selected.filter(option=>option !== value));
        } else {
            onChange(selected.concat(value));
        }
    }
    return <div>
        {options.map(option=>
            <label key={option.value}>
                {option.text}
                <input type={checkbox} checked={selected.includes(option.value)}
                onChange=(this.handleInputChange} name={option} />
            </label>
        )}
    </div>
}
